Transmission

	A	B	D	E	G	H	K	L	M	N	Q	R
1
2				1986 Honda Transmission
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28	Main Shaft:						Counter Shaft:		Starting with Splined Side
29	No.:	Part Name:	OEM Part No.:		Photos:		No.:	Part Name:		OEM Part No.:	Photos:
30	1	Main Shaft	23211-HA2-000				2	Counter Shaft		23221-HA2-000
31
32
33
34
35
36
37
38
39	14	Main Shaft Top - (26T)	23501-HA2-000				19	Thrust Washer (25.2x30)		90431-HA2-000
40
41
42
43
44
45
46
47
48	25	Spline Washer (25mm)	90463-430-000			Note: Blue	10	Counter Shaft 4th (28T)		23471-HA2-000
49
50
51
52
53
54
55
56
57	29	Circlip (Outer - 25mm)	90602-259-010				23	Thrust Washer B (25mm)		90461-286-000		Note: Gray
58
59
60
61
62
63
64
65
66	8	Main Shaft 3rd & 4th	23441-HA2-000				24	Lock Washer (25mm)		90462-323-000
67
68
69
70
71
72
73
74
75	29	Circlip (Outer - 25mm)	90602-259-010				12	Gear Collar		23482-HA2-000
76
77
78
79
80
81
82
83
84	25	Spline Washer (25mm)	90463-430-000			Note: Blue	9	Counter Shaft 3rd (30T)		23451-HA2-000
85
86
87
88
89
90
91
92
93	12	Main Shaft Collar	23482-HA2-000				25	Spline Washer (25mm)		90463-430-000
94
95
96
97
98
99
100
101
102	11	Main Shaft 5th (24T)	2348-HA2-000				29	Circlip (Outer - 25mm)		90602-259-010
103
104
105
106
107
108
109
110
111	23	Thrust Washer B (25mm)	90461-286-000			Note: Gray	16	Counter Shaft "Top" (23T)		23511-HA2-000
112
113
114
115
116
117
118
119
120	24	Lock Washer (25mm)	90462-323-000				28	Thrust Washer (19mm)		90554-KA5-680
121
122
123
124
125
126
127
128
129	5	Main Shaft 2nd (16T)	23421-HA2-000				4	Counter Shaft Collar Low		23412-HA2-000
130
131
132
133
134
135
136
137
138	22	Thrust Washer (17mm)	90454-KF0-000				3	Counter Shaft Low (36T)		23411-HA2-000
139
140
141
142
143
144
145
146
147							22	Thrust Washer (17mm)		90454-KF0-000
148
149
150
151							Flip to work on other side of shaft.
152
153
154
155
156							13	Counter Shaft 5th (26T)		23491-HA2-000
157
158
159
160
161
162
163
164
165							21	Thrust Washer (24.2x34)		90446-KA5-680
166
167
168
169
170
171
172
173
174							7	Counter Shaft Collar		23432-HA2-000
175
176
177
178
179
180
181
182
183							6	Counter Shaft 2nd (33T)		23431-HA2-010
184
185
186
187
188
189
190
191
192								Thrust Washer B (22mm)		90455-ML7-000
